设计模式(Design pattern)是一套被反复使用、多数人知晓的、经过分类编目的、代码设计经验的总结。 使用设计模式是为了可重用代码、让代码更容易被他人理解、保证代码可靠性。 毫无疑问,设计模式于己于他人于系统都是多赢的;设计模式使代码编写真正工程化;设计模式是软件工程的基石脉络,如同大厦的结构一样。
观察者模式 Observer Pattern
Observer模式也叫观察者模式、订阅/发布模式,是由GoF提出的23种软件设计模式的一种。 Observer模式是行为模式之一,它的作用是当一个对象的状态发生变化时,能够自动通知其他关联对象,自动刷新对象状态,或者说执行对应对象的方法。 这种设计模式可以大大降低程序模块之间的耦合度,便于更加灵活的扩展和维护。
观察者模式包含两种角色:
- 观察者(订阅者)
- 被观察者(发布者)
核心思想:观察者只要订阅了被观察者的事件,那么当被观察者的状态改变时,被观察者会主动去通知观察者,而无需关心观察者得到事件后要去做什么,实际程序中可能是执行订阅者的回调函数。
在各种框架中:vue中的$emit
,Angular1.x.x中的$on
、$emit
、$broadcast
,Angular2中的emit
...都是最典型的例子。
简单的例子:
假设你是一个班长,要去通知班里的某些人一些事情,与其一个一个的手动调用触发的方法(私下里一个一个通知),不如维护一个列表(建一个群),这个列表存有你想要调用的对象方法(想要通知的人);
之后每次通知事件的时候只要循环执行这个列表就好了(群发),而不用关心这个列表里有谁。
Javascript中实现一个例子:
- 1
- 2
- 3
// 我们向某dom文档订阅了点击事件,当点击发生时,他会执行我们传入的callback
element.addEventListener(‘click’, callback2, false)
element.addEventListener(‘click’, callback2, false)
我们用Javascript实现一个简单的播放器:
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- 13
- 14
- 15
- 16
- 17
- 18
- 19
- 20
- 21
- 22
- 23
- 24
- 25
- 26
- 27
- 28
- 29
- 30
- 31
- 32
- 33
- 34
- 35
- 36
- 37
- 38
- 39
- 40
- 41
- 42
- 43
- 44
- 45
- 46
- 47
- 48
- 49
- 50
- 51
- 52
- 53
- 54
- 55
- 56
- 57
- 58
- 59
- 60
- 61
- 62
- 63
- 64
- 65
- 66
- 67
- 68
- 69
- 70
- 71
- 72
- 73
- 74
- 75
- 76
- 77
- 78
- 79
- 80
- 81
- 82
- 83
- 84
- 85
- 86
- 87
- 88
- 89
// 一个播放器类
class Player {
constructor() {
// 初始化观察者列表
this.watchers = {}
// 模拟2秒后发布一个'play'事件
setTimeout(() => {
this._publish('play', true)
}, 2000)
// 模拟4秒后发布一个'pause'事件
setTimeout(() => {
this._publish('pause', true)
}, 4000)
}
// 发布事件
_publish(event, data) {
if (this.watchers[event] && this.watchers[event].length) {
this.watchers[event].forEach(callback => callback.bind(this)(data))
}
}
// 订阅事件
subscribe(event, callback) {
this.watchers[event] = this.watchers[event] || []
this.watchers[event].push(callback)
}
// 退订事件
unsubscribe(event = null, callback = null) {
// 如果传入指定事件函数,则仅退订此事件函数
if (callback) {
if (this.watchers[event] && this.watchers[event].length) {
this.watchers[event].splice(this.watchers[event].findIndex(cb => Object.is(cb, callback)), 1)
}
// 如果仅传入事件名称,则退订此事件对应的所有的事件函数
} else if (event) {
this.watchers[event] = []
// 如果未传入任何参数,则退订所有事件
} else {
this.watchers = {}
}
}
}
// 实例化播放器
const player = new Player()
console.log(player)
// 播放事件回调函数1
const onPlayerPlay1 = function(data) {
console.log('1: Player is play, the `this` context is current player', this, data)
}
// 播放事件回调函数2
const onPlayerPlay2 = data => {
console.log('2: Player is play', data)
}
// 暂停事件回调函数
const onPlayerPause = data => {
console.log('Player is pause', data)
}
// 加载事件回调函数
const onPlayerLoaded = data => {
console.log('Player is loaded', data)
}
// 可订阅多个不同事件
player.subscribe('play', onPlayerPlay1)
player.subscribe('play', onPlayerPlay2)
player.subscribe('pause', onPlayerPause)
player.subscribe('loaded', onPlayerLoaded)
// 可以退订指定订阅事件
player.unsubscribe('play', onPlayerPlay2)
// 退订指定事件名称下的所有订阅事件
player.unsubscribe('play')
// 退订所有订阅事件
player.unsubscribe()
// 可以在外部手动发出事件(真实生产场景中,发布特性一般为类内部私有方法)
player._publish('loaded', true)
举个Vue中的例子吧:
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
// 事件发布者使用'vm.$emit、vm.$dispatch(vue1.0)、vm.$broadcast(vue1.0)发布事件
// 接受方使用$on方法或组件监听器订阅事件,传递一个回调函数
vm.$emit(event, […args]) // publish
vm.$on(event, callback) // subscribe
vm.$off([event, callback]) // unsubscribe
// 或者组件中监听事件
<component @event="callback" />
// 在Vue中无论是$on方法还是组件监听事件最终都会转化为实例中的监听器
各框架中观察者模式的实现:
Angularjs(AngularJS 1.x.x)中的实现" rel="external nofollow noopener" > Angularjs(AngularJS 1.x.x)中的实现 ;
同样,Vue中使用Object.defineProperty()
实现对数据的双向绑定,在数据变更时,使用notify
广播事件,最终同样执行对应属性所维护的Watchers
列表进行回调。
中介者模式 Mediator Pattern
中介者在程序设计中非常常见,和观察者模式实现的功能非常相似。
形式上:不像观察者模式那样通过调用pub/sub
的形式来实现,而是通过一个中介者统一来管理。
实质上:观察者模式通过维护一堆列表来管理对象间的多对多关系,中介者模式通过统一接口来维护一对多关系,且通信者之间不需要知道彼此之间的关系,只需要约定好API即可。
简单说:就像一辆汽车的行驶系统,观察者模式中,你需要知道车内坐了几个人(维护观察者列表),当汽车发生到站、停车、开车...这些事件(被订阅者事件)时,你需要给这个列表中订阅对应事件的的每个人进行通知; 在中介者模式中,你只需要在车内发出广播(到站啦、停车啦、上车啦...请文明乘车尊老爱幼啦...),而不用关心谁在车上,谁要上车谁要下车,他们自己根据广播做自己要做的事,哪怕他不听广播,听了也不做自己要做的事都无所谓。
中介者模式包含两种角色:
- 中介者(事件发布者)
- 通信者
Javascript中实现一个例子:
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- 13
- 14
- 15
- 16
- 17
- 18
- 19
- 20
- 21
- 22
- 23
- 24
- 25
- 26
- 27
- 28
- 29
- 30
- 31
- 32
- 33
- 34
- 35
- 36
- 37
- 38
- 39
- 40
- 41
- 42
- 43
- 44
- 45
- 46
- 47
- 48
- 49
- 50
- 51
- 52
- 53
- 54
- 55
- 56
- 57
- 58
- 59
- 60
- 61
- 62
- 63
- 64
- 65
- 66
- 67
- 68
- 69
- 70
- 71
- 72
- 73
- 74
- 75
- 76
- 77
- 78
- 79
- 80
- 81
- 82
- 83
- 84
- 85
- 86
- 87
- 88
- 89
- 90
- 91
- 92
- 93
- 94
- 95
- 96
- 97
- 98
- 99
- 100
- 101
- 102
- 103
- 104
// 汽车
class Bus {
constructor() {
// 初始化所有乘客
this.passengers = {}
}
// 发布广播
broadcast(passenger, message = passenger) {
// 如果车上有乘客
if (Object.keys(this.passengers).length) {
// 如果是针对某个乘客发的,就单独给他听
if (passenger.id && passenger.listen) {
// 乘客他爱听不听
if (this.passengers[passenger.id]) {
this.passengers[passenger.id].listen(message)
}
// 不然就广播给所有乘客
} else {
Object.keys(this.passengers).forEach(passenger => {
if (this.passengers[passenger].listen) {
this.passengers[passenger].listen(message)
}
})
}
}
}
// 乘客上车
aboard(passenger) {
this.passengers[passenger.id] = passenger
}
// 乘客下车
debus(passenger) {
this.passengers[passenger.id] = null
delete this.passengers[passenger.id]
console.log(`乘客${passenger.id}下车`)
}
// 开车
start() {
this.broadcast({ type: 1, content: '前方无障碍,开车!Over'})
}
// 停车
end() {
this.broadcast({ type: 2, content: '老司机翻车,停车!Over'})
}
}
// 乘客
class Passenger {
constructor(id) {
this.id = id
}
// 听广播
listen(message) {
console.log(`乘客${this.id}收到消息`, message)
// 乘客发现停车了,于是自己下车
if (Object.is(message.type, 2)) {
this.debus()
}
}
// 下车
debus() {
console.log(`我是乘客${this.id},我现在要下车`, bus)
bus.debus(this)
}
}
// 创建一辆汽车
const bus = new Bus()
// 创建两个乘客
const passenger1 = new Passenger(1)
const passenger2 = new Passenger(2)
// 俩乘客分别上车
bus.aboard(passenger1)
bus.aboard(passenger2)
// 2秒后开车
setTimeout(bus.start.bind(bus), 2000)
// 3秒时司机发现2号乘客没买票,2号乘客被驱逐下车
setTimeout(() => {
bus.broadcast(passenger2, { type: 3, content: '同志你好,你没买票,请下车!' })
bus.debus(passenger2)
}, 3000)
// 4秒后到站停车
setTimeout(bus.end.bind(bus), 3600)
// 6秒后再开车,车上已经没乘客了
setTimeout(bus.start.bind(bus), 6666)
上面例子中(当然,稍微扩展了点哈),Bus即为中介者对象,乘客为通信者,乘客具有一些统一的方法API,Bus只管开车停车发广播,执行自己的事物,乘客在不断地接受广播,根据广播信息的类型和内容作出自己的判断,执行事务。
代理模式 Proxy Pattern
简单说就是:为对象提供一种代理以控制对这个对象的访问。
代理模式使得代理对象控制具体对象的引用。代理几乎可以是任何对象:文件,资源,内存中的对象,或者是一些难以复制的东西。
举个例子: 一个工厂制造商品(目标对象),你可以给这个工厂设置一个业务代理(代理对象),提供流水线管理,订单,运货,淘宝网店等多种行为能力(扩展属性)。 当然,里面还有最关键的一点就是,这个代理能把一些骗纸和忽悠都过滤掉,将最真实最直接的订单给工厂,让工厂能够专注于生产(控制访问)。
上面工厂的例子:
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- 13
- 14
- 15
- 16
- 17
- 18
- 19
- 20
- 21
- 22
- 23
- 24
- 25
- 26
- 27
- 28
- 29
- 30
- 31
- 32
- 33
- 34
- 35
- 36
- 37
- 38
- 39
- 40
- 41
- 42
- 43
- 44
- 45
- 46
- 47
- 48
- 49
- 50
- 51
- 52
- 53
- 54
- 55
- 56
- 57
- 58
- 59
- 60
- 61
- 62
- 63
- 64
- 65
- 66
// 真实工厂
class Factory {
constructor(count) {
// 工厂默认有1000件产品
this.productions = count || 1000
}
// 生产商品
produce(count) {
// 原则上低于5个工厂是不接单的
this.productions += count
}
// 向外批发
wholesale(count) {
// 原则上低于10个工厂是不批发的
this.productions -= count
}
}
// 代理工厂
class ProxyFactory extends Factory {
// 代理工厂默认第一次合作就从工厂拿100件库存
constructor(count = 100) {
super(count)
}
// 代理工厂向真实工厂下订单之前会做一些过滤
produce(count) {
if (count > 5) {
super.produce(count)
} else {
console.log('低于5件不接单')
}
}
wholesale(count) {
if (count > 10) {
super.wholesale(count)
} else {
console.log('低于10件不批发')
}
}
taobao(count) {
// ...
}
logistics() {
// ...
}
}
// 创建一个代理工厂
const proxyFactory = new ProxyFactory()
// 通过代理工厂生产4件商品,被拒绝
proxyFactory.produce(4)
// 通过代理工厂批发20件商品
proxyFactory.wholesale(20)
// 代理工厂的剩余商品 80
console.log(proxyFactory.productions)
ES6中的Proxy
对象:
ES6中Proxy
对象可以理解为:在目标对象之前架设一层“拦截”,外界对该对象的访问,都必须先通过这层拦截,因此提供了一种机制,可以对外界的访问进行过滤和改写。Proxy 这个词的原意是代理,用在这里表示由它来“代理”某些操作,可以译为"代理器"。
基本形式:
- 1
- 2
// 参数分别为目标对象和代理解析器
var proxy = new Proxy(target, handler)
无操作转发代理:
- 1
- 2
- 3
- 4
const target = {}
const p = new Proxy(target, {})
p.a = 3 // 被转发到代理的操作
console.log(target.a) // 3 操作已经被正确地转发至目标对象
使用错误拦截属性读取操作:
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- 13
- 14
- 15
- 16
const handler = {
get(target, property) {
if (property in target) {
return target[property]
} else {
throw new ReferenceError("Property \"" + property + "\" does not exist.")
}
}
}
const p = new Proxy({}, handler)
p.a = 1
p.b = undefined
console.log(p.a, p.b) // 1, undefined
console.log('c' in p, p.c) // Uncaught ReferenceError: Property "c" does not exist.
实现一个service客户端:
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- 13
- 14
- 15
- 16
- 17
- 18
function createWebService(baseUrl) {
return new Proxy({}, {
get(target, propKey, receiver) {
return () => httpGet(baseUrl+'/' + propKey)
}
})
}
const serviceA = createWebService('http://example.com/data-a')
const serviceB = createWebService('http://example.com/data-b')
const serviceC = createWebService('http://example.com/data-c')
serviceA.employees().then(json => {
const employees = JSON.parse(json)
// ···
})
serviceB...
单例模式 Singleton Pattern
简单说:保证一个类只有一个实例,并提供一个访问它的全局访问点(调用一个类,任何时候返回的都是同一个实例)。
实现方法:使用一个变量来标志当前是否已经为某个类创建过对象,如果创建了,则在下一次获取该类的实例时,直接返回之前创建的对象,否则就创建一个对象。
类/构造函数实例:
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- 13
- 14
- 15
- 16
- 17
- 18
- 19
- 20
- 21
- 22
- 23
class Singleton {
constructor(name) {
this.name = name
this.instance = null
}
getName() {
alert(this.name)
}
static getInstance(name) {
if (!this.instance) {
this.instance = new Singleton(name)
}
return this.instance
}
}
const instanceA = Singleton.getInstance('seven1')
const instanceB = Singleton.getInstance('seven2')
console.log(instanceA, instanceB)
闭包包装实例:
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- 13
- 14
- 15
- 16
- 17
- 18
- 19
- 20
- 21
- 22
- 23
- 24
- 25
const SingletonP = (function() {
let instance
return class Singleton {
constructor(name) {
if (instance) {
return instance
} else {
this.init(name)
instance = this
return this
}
}
init(name) {
this.name = name
console.log('已初始化')
}
}
})()
const instanceA = new SingletonP('seven1')
const instanceB = new SingletonP('seven2')
console.log(instanceA, instanceB)
惰性包装实例:
- 1
- 2
- 3
- 4
- 5
- 6
- 7
const getSingle = function (fn) {
let result
return function() {
return result || (result = fn.apply(this, arguments))
}
}
工厂模式 Factory Pattern
与创建型模式类似,工厂模式创建对象(视为工厂里的产品)时无需指定创建对象的具体类。 工厂模式定义一个用于创建对象的接口,这个接口由子类决定实例化哪一个类。该模式使一个类的实例化延迟到了子类。而子类可以重写接口方法以便创建的时候指定自己的对象类型。
简单说:假如我们想在网页面里插入一些元素,而这些元素类型不固定,可能是图片、链接、文本,根据工厂模式的定义,在工厂模式下,工厂函数只需接受我们要创建的元素的类型,其他的工厂函数帮我们处理。
上代码:
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- 13
- 14
- 15
- 16
- 17
- 18
- 19
- 20
- 21
- 22
- 23
- 24
- 25
- 26
- 27
- 28
- 29
- 30
- 31
- 32
- 33
- 34
- 35
- 36
- 37
- 38
- 39
- 40
- 41
- 42
- 43
- 44
- 45
- 46
- 47
- 48
- 49
- 50
- 51
- 52
- 53
- 54
- 55
- 56
- 57
- 58
// 文本工厂
class Text {
constructor(text) {
this.text = text
}
insert(where) {
const txt = document.createTextNode(this.text)
where.appendChild(txt)
}
}
// 链接工厂
class Link {
constructor(url) {
this.url = url
}
insert(where) {
const link = document.createElement('a')
link.href = this.url
link.appendChild(document.createTextNode(this.url))
where.appendChild(link)
}
}
// 图片工厂
class Image {
constructor(url) {
this.url = url
}
insert(where) {
const img = document.createElement('img')
img.src = this.url
where.appendChild(img)
}
}
// DOM工厂
class DomFactory {
constructor(type) {
return new (this[type]())
}
// 各流水线
link() { return Link }
text() { return Text }
image() { return Image }
}
// 创建工厂
const linkFactory = new DomFactory('link')
const textFactory = new DomFactory('text')
linkFactory.url = 'https://surmon.me'
linkFactory.insert(document.body)
textFactory.text = 'HI! I am surmon.'
textFactory.insert(document.body)
double click three sixes
reply:
🌚🌚🌚
